Product Lineup and Specifications of KD6R106SX Series for Surface Inspection Applications
| Specifications | Download |
- Simple installation! Compact!
- Scan width 106mm
- Working distance 1.3mm
- GigE Vision®
- Mono scanning
Specifications
| Item | KD6R106SX | |
| Scan width | ㎜ | 106 |
| Valid pixels | Pixel | 2,496 |
| Resolution | dpi | 600 |
| Output data format | – | GigE Vision® 2.0 |
| Scan speed | kHz/line | 6 |
| Power | – | 5V × 1ch (2A max.) |
| Light source | – | Red LED (660nm) |
| Exposure control | – | LED pulse control |
| Focal point | ㎜ | 1.3 (from glass surface) |
| Size (L×W×H) | ㎜ | 137.7 × 48 × 46.1 |
| Weight | g | 184 |
| Regulatory compliance | – | RoHS |
* Please download outline drawings here.
GigE Vision® is a registered trade mark of AIA (Automated Imaging Association).
